WARP4 Charger

The fully-equipped charger.

from €842 incl. VAT

Configure
WARP4 Charger
  • Choose between brushed stainless steel or stainless steel powder-coated in DB703. Both finishes are UV-resistant and approved for outdoor use.
  • Enables Autocharge, i.e. vehicle identification via the charging cable. The SoC can be read out. Pro version: hardware-side prepared for bidirectional charging (V2H/V2G).
  • All features run locally on the charger. No cloud requirement, no telemetry.
  • PV excess charging, dynamic tariff, eco mode, solar forecast and charge management integrated. Compatible with over 100 devices from other manufacturers.
  • Designed and manufactured by Tinkerforge in Schloß Holte-Stukenbrock, includes a 3-year warranty.
help
What is the WARP4 Charger?

The fully-equipped charger.

The WARP4 Charger is the high-quality open-source charger with up to 22 kW charging power, made in Germany. It is built for longevity, has a modular design and is already prepared for bidirectional charging.

Thanks to its compatibility with over 100 devices from other manufacturers (including electricity meters, PV inverters and battery storage), it integrates easily into existing systems.

As a fully-equipped charger, the WARP4 Charger offers integrated PV excess charging, eco mode for intelligently combining solar forecast data, dynamic electricity prices and PV excess, static or dynamic load management over the network, and numerous open interfaces.

auto_awesome
Maximum self-consumption

The right behavior for every situation.

Intelligent energy management

All features run directly on the WARP4, with no additional hardware or external energy-management system. Over 100 compatible devices are directly supported.

tune
Your choice

The right model for every use case.

Smart

from 842€ incl. VAT
Configure

Features:

  • Eligible for subsidies
  • LAN/WLAN, web interface
  • NFC release, Autocharge
  • Remote access & apps
  • Phase switching (1ph/3ph)
  • PV excess charging & solar forecast data
  • Dynamic tariff
  • Static or dynamic load management
  • Charging log without energy capture
  • ISO15118
  • Compatible with over 100 devices
  • HTTP, MQTT, Modbus/TCP, OCPP, EEBUS

Pro

from 1042€ incl. VAT
Configure

Everything from Smart, plus:

  • Charging power measurement
  • MID-certified electricity meter
  • Charging log with energy capture
  • Improved charge management
  • Reading the EV's state of charge (SoC)
  • Prepared for bidirectional charging
help
FAQs

Any more questions?

Who is allowed to install the WARP4 Charger? expand_more
Installation must be carried out by a qualified electrician. They also handle the required registration with the grid operator.
Do I need a Type B RCD? expand_more
No. The WARP4 has an integrated DC residual current detection (RDC-DD). A Type A RCD in the building's installation is sufficient.
Does WARP4 also work without internet access/cloud? expand_more
All WARP4 features run locally on the charger. Operation and configuration happen via the built-in web interface on your home network, entirely without any cloud requirement. Only functions such as the solar forecast, the use of dynamic electricity prices and the use of the apps require an internet connection.
How do I integrate the charger into my smart home? expand_more
The WARP4 supports open standards such as MQTT, Modbus TCP and an HTTP API. This allows seamless integration with Home Assistant, ioBroker, openHAB and other smart-home systems.
How do I connect the charger to my existing PV system? expand_more
We support over 100 devices from other manufacturers and can access data from electricity meters, PV inverters and battery storage systems directly. Installing additional hardware, such as a dedicated meter for the charger, is therefore usually not needed since existing hardware can be used by the charger. See the full compatibility list on our solutions page.
Which devices are supported? expand_more
The WARP4 communicates with numerous smart meters, PV inverters, electricity storage systems and heat pumps from various manufacturers. A complete compatibility list is available in the documentation.
Why is only the Pro version prepared for bidirectional charging and able to read out the SoC expand_more
Only the Pro version has a built-in energy meter. We assume this is required for bidirectional charging in order to react to grid issues (anti-island protection / NA protection). A vehicle's SoC can be read out via ISO15118-2, but unfortunately not during an ongoing charging session. The Pro is able to keep track of the state of charge during the charging process with its energy meter.
Which variant is suitable for billing? expand_more
For billing scenarios such as company EVs or in the workplace, we recommend the WARP4 Pro with MID-certified meter and charging log with energy capture. WARP4 is currently not suitable for applications that require a calibration-law-compliant (eichrechtskonform) solution.
Is the charger eligible under the 'Charging in Multi-Dwelling Buildings' subsidy? expand_more
Yes, WARP4 is listed among the eligible chargers under our company name 'Tinkerforge GmbH'.
Does WARP4 comply with §14a EnWG? expand_more
Yes. The WARP4 supports grid-compliant control as per §14a EnWG including an EEBUS interface for communication with the grid operator's control box standard.
